Shipping - Material Weights
The following information on approximate material weights is provided to assist our customers in estimating shipping for their orders. If you have additional questions regarding the shipping requirements for your order, please contact us directly.
Commercial Grade Silicone Weights Per Linear Yd. | ||||||
---|---|---|---|---|---|---|
Width | 1/32″ | 1/16″ | 3.32″ | 1/8″ | 3/16″ | 1/4″ |
36″ | 2.02# | 4.04# | 6.06# | 8.08# | 12.10# | 16.14# |
48″ | 2.69# | 5.37# | 8.08# | 10.71# | 16.16# | 21.52# |
High Strength Silicone Weights Per Linear Yd. | ||||||
---|---|---|---|---|---|---|
Width | .030″ | .040″ | .050″ | .060″ | .085″ | .125″ |
36″ | 1.71# | 2.25# | 2.79# | 3.33# | 4.69# | 6.48# |
Commercial Grade Viton® Weights Per Linear Yd. | ||||||
---|---|---|---|---|---|---|
Width | 1/32″ | 1/16″ | 3/32″ | 1/8″ | 3/16″ | 1/4″ |
36″ | 2.84# | 5.67# | 8.51# | 11.35# | 17.23# | 22.70# |
48″ | 3.79# | 7.56# | 11.35# | 15.13# | 22.97# | 30.27# |
Mosites #2902 Fluoroelastomer Weights Per Linear Yd. | ||||||
---|---|---|---|---|---|---|
Width | 1/32″ | 1/16″ | 1/8″ | 3/16″ | 1/4″ | |
36″ | 2.25# | 4.68# | 9.27# | 13.86# | 18.45# |
Mosites #651 Sheet Size & Weight Table | |||
---|---|---|---|
Sheet | Approx. Weight | ||
Thickness | Sheet Size | lbs. Per Sheet | |
1/4″ | 36″ x 36″ | 19 | |
1/4″ | 36″ x 48″ | 25 | |
1/4″ | 42″ x 60″ | 37 | |
1/2″ | 36″ x 36″ | 38 | |
1/2″ | 36″ x 48″ | 50 | |
1/2″ | 42″ x 60″ | 73 | |
3/4″ | 36″ x 36″ | 57 | |
3/4″ | 36″ x 48″ | 75 | |
3/4″ | 42″ x 60″ | 110 | |
1″ | 36″ x 36″ | 75 | |
1″ | 36″ x 48″ | 100 | |
1″ | 42″ x 60″ | 147 |
