Hydroform Rubber Wear Pads
Mosites Rubber Company has supplied rubber parts to the metal forming industry for a number of years. Mosites #651 is specially compounded for optimum performance in forming rubber applications. These operations include but are not limited to bladder hydro-forming, hydro-presses, fluid forming, diaphragm forming, bulge forming, drop hammer and metal spinning.
These pads are used on hydroforming presses, bladder press equipment, and drop hammer machines. A full range of hardnesses are available for optimum forming of each type and thickness of metal blank. The pads are available in standard widths, lengths and thicknesses, but Mosites Rubber Company also offers custom molded pads in various shapes up to 12 inches in thickness. All Mosites #651 Forming Rubber Pads are non-marking, cream color formulations and thus can eliminate cleaning operations on the formed pads. Another advantage is the good resistance of Mosites #651 to the deteriorating effects of machine oil or rust preventative commonly applied to metal surfaces.
Our Hydroform Rubber Wear Pad Products
Showing all 2 results
651 – Forming – Rubber Sheets
796 Red Semi-Cured Drop-Hammer Rubber Compound
Custom thickness & widths available upon request. Minimum order may be required.
The physical properties shown below were obtained in molded 0.080-inch thick molded ASTM samples. They are typical of the various Mosites Rubber Company # 651 compounds, but they should not be used to set Quality Control Specification minimum requirements.
|Typical Physical Properties|
|Hardness (Shore A)||55||65||70||78||85|
|Tensile Strength (psi)||2400||2750||3000||2850||3000|
|Modulus at 300% Elongation (psi)||750||1050||1250||2000||2400|
|Tear Strength (ppi)||225||350||375||350||350|
Mosites #651 Wear Pads are an industry standard when it comes to forming operations. Available in hardness of 50 durometer to 90 durometer and numerous diameter and shaped pad sizes. A large number of stock sizes are available. Custom molded sizes available on request.
Available in 50, 60, 70 and 90 Durometer
- Mosites #651 Wear Pads are Non-Marking (Cream Color).
- Other diameters and thicknesses quoted on request.
Standard Diameter Thickness Table
